Description
Amplifier
Channel Configuration
4ch
High Pass Filter
120 Hz
High-Pass Filter Slope
12 dB/oct
Low Pass Filter
120 Hz
Low-Pass Filter Slope
12 dB/oct
Details
Current drain (A) – rated output power at 4 ohm
15 A
Line In: Input Sensitivity
1 V/8 V
MOSFET
Yes/Yes
CTA Power output
45 W x 4
CTA SN Ratio
83 dBA
General Features
Frequency Response
20-20 kHz
Signal to Noise Ratio
100 dB
Tolerance
+0.5/-3 dB
Total Harmonic Distortion at 1 kHz (%)
0.08%
Maximum Output Power (1 kHz)
Max. Channel Power Configuration at 4 ohm
100 W x 4
Rated Output Power, RMS 20 – 20000 Hz
Max. Channel Configuration at 2 ohm (W) / THD (%)
45 W x 4/1.0%
Max. Channel Configuration at 4 ohm (W) / THD (%)
45 W x 4/1.0%
Size & Weight
Dimensions (W x H x D)
62.6 x 37.3 x 162.8
Weight
1.01 lb
