Item Dimensions LxWxH 9.5 x 3.75 x 14.5 inches
Manufacturer Electtromedia
Brand HERTZ
About this item
Unit Dimensions (W x H x D mm/inch): 315 x 190 x 50 / 12.40 x 7.48 x 1.97
Weight: 5.66 lbs
RMS Power: 100W x 2Ch
Sensitivity: 83dB
CEA Compliant: Yes
Note: Products with electrical plugs are designed for use in the US. Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.
General Specifications
POWER SUPPLY
Operating power supply voltage 11 ÷ 15 VDC / 2 x 30A
Power supply 6.5V ÷ 17V
Idling current 1.6 A
Switched off 1.7mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power 55 A
Remote IN voltage 6 ÷ 15 VDC (1 mA)
Remote OUT voltage 4 ÷ 15 VDC (150 mA)
Audio Specifications
AMPLIFIER STAGE
Distortion – THD @ 1 kHz, 4Ω, 70% Rated Power 0.06%
Damping factor @ 1 kHz, 4Ω, 2 VRMS > 110
Bandwidth @ -1.5 dB 10Hz ÷ 22kHz
S/N ratio (A weighted @ 1 V Input) Master Input 100 dBA
S/N ratio (A weighted @ 1 V Input) Optical Input 105 dBA
Input sensitivity Pre-In 0.6 ÷ 6 VRMS
Input sensitivity Speaker-In 2.2 ÷ 22 VRMS
Minimum load impedance 8Ch: 2Ω
4Ch – (Bridge 1/2; 3/4; 5/6; 7/8) : 4Ω
OUTPUT POWER (RMS) @28.8 VDC, 1% THD:
8Ch @ 4Ω 85 W x 8
8Ch @ 2Ω 130 W x 8
4Ch (Bridge 1/2; 3/4; 5/6; 7/8) @ 4Ω 260 W x 4
Digital Signal Processor
Filter type Full / High pass / Low pass / Band pass
Filter model and slope Butterworth (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct)
Linkwitz-Riley (12, 24, 36, 48, 60 dB/oct)
Bessel (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct)
Chebyshev (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct)
QLP quasi-linear phase (6, 12 dB/oct)
Crossover frequency 20 Hz – 20000 Hz integer values
Phase control 0 ° – 180°, all pass equalizer poles
Output equalizer Graphic and Parametric modes
n. 10 parametric poles (Peaking, High Shelf, Low Shelf, Notch, All pass) ±12 dB gain, variable Q (0.5 – 16.0)
n. 10 graphic poles
Time alignment distance 0 – 510 cm (0 – 200.8 inches)
Time alignment delay 0 – 15 ms
Time alignment step 1 cm
Time alignment fine set step 1 sample
Memories n. 2 memories
n. 3 parametric poles for each memory (Peaking, High Shelf, Low Shelf) ±12 dB gain, variable Q (0.5 – 16.0)
Preset Rotary switch for 7 installation presets
Physical Specs
Max size W x H x D (mm/inch) 238 x 49,5 x 155 / 9.37 x 1.95 x 6.1
Weight (kg/lbs) 1,98 / 4.36
