Marine Amplifiers

HCP 1MDKCh: 1 | 1240 W
HCP 1MDK mono marine amplifierfeatures latest generation D-Class 2Ω stable output stage reaching the impressive RMS power of 740 W x 1 (4 Ω). Engineered and tested for the real environment of application (UV, salt-fog, vibrations, high/low temperature, thermal shock, dust), HCP 1MDK features a compact design built from extruded aluminium heatsink with top side ensuring effective heat transfer. The special balanced input circuitry reject electro-magnetic disturbances and the Hi-Level and lo-level inputs are compatible with any source. The Adjustable Bass Boost (50 Hz) with continuity between 0 dB and 6 dB adds more punch to subwoofer and SUBSONIC filter (24 dB – 25 Hz), removes very low subsonic frequencies from music signal to prevent damage to the subwoofer. The continuously adjustable PHASE control (0 to 180°) optimizes alignment of woofer bass frequencies with sub ones. The Optional Remote Volume Control (HRC) provides the ability to adjust subwoofer volume level from the dashboard.

‘
Item Dimensions LxWxH 9.5 x 3.75 x 14.5 inches
Manufacturer Electtromedia
Brand HERTZ

About this item

Unit Dimensions (W x H x D mm/inch): 315 x 190 x 50 / 12.40 x 7.48 x 1.97
Weight: 5.66 lbs
RMS Power: 100W x 2Ch
Sensitivity: 83dB
CEA Compliant: Yes

Note: Products with electrical plugs are designed for use in the US. Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.

‘
Item Dimensions LxWxH 9.5 x 3.75 x 14.5 inches
Manufacturer Electtromedia
Brand HERTZ
Number of Channels 4

About this item

Unit Dimensions (W x H x D mm/inch): 315 x 190 x 50 / 12.40 x 7.48 x 1.97
Weight: 5.7 lbs
RMS Power: 50W x 4 Ch
Sensitivity: 82dB
CEA Compliant: Yes

Note: Products with electrical plugs are designed for use in the US. Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.

Voltage 1 Volts
Manufacturer Hertz
Brand HERTZ
Number of Channels 5

Unit Dimensions (W x H x D mm/inch): 355 x 190 x 50 / 13.58” x 7.48” x 1.97”
Weight: 5.7 lbs
RMS Power: 50W x 4 Ch
Sensitivity: 83dB
CEA Compliant: Yes

Note: Products with electrical plugs are designed for use in the US. Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.

FEATURES:

Channel Mode: 1
Distortion – THD (100Hz @ 4 Ohm): 0.1%
S/N Ratio (A weighted @ 1V): 110dBA
Damping Factor (100Hz @ 4 Ohm): 140
Size (W x D x H) inches: 9.56″ x 1.8″ x 6.25″

Products with electrical plugs are designed for use in the US. Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.

General Specifications

POWER SUPPLY
Operating power supply voltage 11 ÷ 15 VDC / 2 x 30A
Power supply 6.5V ÷ 17V
Idling current 1.6 A
Switched off 1.7mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power 55 A
Remote IN voltage 6 ÷ 15 VDC (1 mA)
Remote OUT voltage 4 ÷ 15 VDC (150 mA)

Audio Specifications
AMPLIFIER STAGE
Distortion – THD @ 1 kHz, 4Ω, 70% Rated Power 0.06%
Damping factor @ 1 kHz, 4Ω, 2 VRMS > 110
Bandwidth @ -1.5 dB 10Hz ÷ 22kHz
S/N ratio (A weighted @ 1 V Input) Master Input 100 dBA
S/N ratio (A weighted @ 1 V Input) Optical Input 105 dBA
Input sensitivity Pre-In 0.6 ÷ 6 VRMS
Input sensitivity Speaker-In 2.2 ÷ 22 VRMS
Minimum load impedance 8Ch: 2Ω
4Ch – (Bridge 1/2; 3/4; 5/6; 7/8) : 4Ω
OUTPUT POWER (RMS) @28.8 VDC, 1% THD:
8Ch @ 4Ω 85 W x 8
8Ch @ 2Ω 130 W x 8
4Ch (Bridge 1/2; 3/4; 5/6; 7/8) @ 4Ω 260 W x 4

Digital Signal Processor
Filter type Full / High pass / Low pass / Band pass
Filter model and slope Butterworth (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct)
Linkwitz-Riley (12, 24, 36, 48, 60 dB/oct)
Bessel (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct)
Chebyshev (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct)
QLP quasi-linear phase (6, 12 dB/oct)
Crossover frequency 20 Hz – 20000 Hz integer values
Phase control 0 ° – 180°, all pass equalizer poles
Output equalizer Graphic and Parametric modes
n. 10 parametric poles (Peaking, High Shelf, Low Shelf, Notch, All pass) ±12 dB gain, variable Q (0.5 – 16.0)
n. 10 graphic poles
Time alignment distance 0 – 510 cm (0 – 200.8 inches)
Time alignment delay 0 – 15 ms
Time alignment step 1 cm
Time alignment fine set step 1 sample
Memories n. 2 memories
n. 3 parametric poles for each memory (Peaking, High Shelf, Low Shelf) ±12 dB gain, variable Q (0.5 – 16.0)
Preset Rotary switch for 7 installation presets

Physical Specs
Max size W x H x D (mm/inch) 238 x 49,5 x 155 / 9.37 x 1.95 x 6.1
Weight (kg/lbs) 1,98 / 4.36
